4 Channel Relay Module 5V 12V 24V Board Shield With Optocoupler Isolation Support High and Low Level Trigger for Rasp Pi Arduino

Warm Tips:
Our store support wholesale, the more quantity the more discount.
If you want to bulk order, please feel free to contact seller for wholesale price, looking forward to receive your inquiry, thanks! ^_^

1. Maximum load:AC 250V/10A, DC30V/10A
2. SMD optocoupler isolation, strong driving ability, stable performance; trigger current 5mA
3. The module voltage 5V 12V 24V
4. Each channel module can be set high or low triggered by jumper
5. Fault-tolerant design, even if the control line is broken, the relay will not operate
6. Power indicator (green), 4 relay state indicator (red)
7. Interface design user-friendly, all interfaces are available through the wiring terminal direct connection leads, very convenient

Module Port:
1. DC+: DC power supply positive
2. DC-:   DC power supply negative
3. IN1:   Channel 1 signal trigger terminal
4. IN2:   Channel 2 signal trigger terminal
5. IN3:   Channel 3 signal trigger terminal
6. IN4:   Channel 4 signal trigger terminal

Relay Output:
1. NC1:     Channel 1 relay normally closed pin.
2. COM1:  Channel 1 relay common pin.
3. NO1:     Channel 1 relay normally opened pin.
4. NC2:     Channel 2 relay normally closed pin.
5. COM2:  Channel 2 relay common pin.
6. NO2:     Channel 2 relay normally opened pin.
7. NC3:     Channel 2 relay normally closed pin.
8. COM3:  Channel 2 relay common pin.
9. NO3:     Channel 2 relay normally opened pin.
10. NC4:     Channel 2 relay normally closed pin.
11. COM4:  Channel 2 relay common pin.
12. NO4:     Channel 2 relay normally opened pin.

High And Low Level Trigger Option:
1. S1:   It is option switch for channel 1 relay.
2. S2:   It is option switch for channel 2 relay.
3. S3:   It is option switch for channel 3 relay.
4. S4:   It is option switch for channel 4 relay.
