5Pcs WH148 B1K B2K B5K B10K B20K B50K B100K B500K 3Pin 20mm Shaft Amplifier Potentiometer 1K 2K 5K 10K 50K 100K 500K

Specification:

Model: B1K B2K B5K B10K B20K B50K B100K B500K

Type: WH148 Potentiometer

Feature:

Rotation angle: 300°±10

Rotation torque: 10200gf.com

Stopping strength: 6. kgf. cn Min

Shaft push-pull strength: 8. kgf, cm

Anchor point location: Center, 7/11/21/41 Detent

Point power moment: 50 150gfcm

Resistance range: 10k Q2"1MQ

Resistance tolerance: ±20%（ more than1MΩ±30%

Load power: Curve B: 0.05W, other yhan B: 0.025W

Operating voltage: Curve B: 50VdC other than B: 25V AV

Residual short-term rental: R≥25KQ0.1%max, of total tesistance

250K Q2>R>10K Q2 20Q2 max 20KQ>R 10K Q2 max

Insulation resistance: More than 100M Q at DC 250V 1minute

Withstand voltage: 1 minute AC 250V

Synchronization error: 400dB≤±3dB

Rotation noise: less than 100mV

Rotation life: 10000cycles

Packgae Include:

5Pcs/Lot x WH148

Model: As your choice!

Quantity: As your choice!

(We have a lot of Stocks,if you need more, please contact us.)

10K Ohm

50K Ohm

250K Ohm

20K Ohm

100K Ohm

500K Ohm
