Product parameter:

Output voltage range: 3V~5.5V, the input voltage needs to be lower than the set output voltage

The output voltage can be set to 5V/8V/9V/12V, the default is 12V

Output capability: when input by 3.6V lithium battery, it can output 5V1.5A, 8V1A, 12V0.8A;

When input at 5V, it can output 8V1.2A, 9V1.2A, 12V1A

When the default 12V output, the LED indicator consumes about 1mA (the input current is about 3mA)

If the indicator light is turned off, the input current is less than 1mA at no load

size: 2.7*1.7*0.46cm

Voltage setting instructions:

The words A and B can be seen on the front of the PCB. Use an electric soldering iron to change the on-off of the pad next to the character to change the output voltage.

A: Disconnect B: Disconnect VOUT 5V

A: Disconnect B: Connect VOUT 8V

A: Connect B: Disconnect VOUT 9V

A: Connected B: Connected to VOUT 12V

The pad next to the LED indicator can also be disconnected to turn off the indicator
