SN74HC Series DIP-14 Logic ICs – 74HC00/02/03/04/125/164/06, Pack of 5

SN74HC Series DIP-14 Logic ICs — 74HC00 / 02 / 03 / 04 / 125 / 164 / 06 (5-Pack)

This listing covers the popular SN74HC series DIP-14 CMOS logic ICs in a 5-pack. Select your required variant from the dropdown — each IC is a fundamental digital logic building block operating from 2V to 6V with high-speed CMOS performance and TTL-compatible inputs.

Available Variants

Part Number	Function	Gates/Channels
74HC00	Quad 2-Input NAND Gate	4× NAND
74HC02	Quad 2-Input NOR Gate	4× NOR
74HC03	Quad 2-Input NAND (Open Drain)	4× NAND OD
74HC04	Hex Inverter (NOT Gate)	6× NOT
74HC125	Quad Bus Buffer (3-State)	4× Buffer
74HC164	8-Bit Serial-In Parallel-Out Shift Register	8-bit SIPO
74HC06	Hex Inverter (Open Drain)	6× NOT OD

Common Specifications (All Variants)

Parameter	Value
Logic Family	74HC CMOS
Package	DIP-14
Supply Voltage	2V – 6V
Propagation Delay	~7ns @ VCC=5V
Output Drive Current	±25mA @ VCC=4.5V
Input Type	TTL-compatible
Quantity	5 pieces per variant

Why Choose SN74HC Series?

• High-Speed CMOS — ~7ns propagation delay, 10× faster than 4000-series CMOS
• TTL-Compatible Inputs — Direct interface with 5V TTL logic without level shifting
• Wide Supply Range — 2V–6V covers 3.3V and 5V systems
• ±25mA Output Drive — Directly drives LEDs, bus lines, and logic inputs
• DIP-14 Package — Breadboard-friendly for prototyping and education

Typical Applications by Variant

• 74HC00/02/03 — Universal logic gates (implement any Boolean function)
• 74HC04/06 — Signal inversion, level conversion, open-drain bus pull-down
• 74HC125 — Bus buffering, 3-state output for shared data buses
• 74HC164 — Serial-to-parallel conversion, LED matrix driving, SPI expansion

FAQ

Q: What’s the difference between 74HC and 74HCT?
A: 74HC has CMOS-level input thresholds (VIH = 0.7×VCC); 74HCT has TTL-level thresholds (VIH = 2.0V fixed). Use 74HCT when interfacing with 5V TTL outputs in a 5V system.

Q: Can 74HC series run at 3.3V?
A: Yes — 74HC operates from 2V–6V. At 3.3V, input thresholds scale accordingly (VIH ≈ 2.3V).

Package Contents

• 5× SN74HC [selected variant] DIP-14 Logic IC
