Waterproof Heat Shrink Tubing 4:1 Heat Shrink Tube Wiring Accessories Transparent Insulation Cable Sleeve Heat Shrink Tubing Kit

Transparent Heat Shrink Tubing — 2:1 EVA, 1–2.5mm Inner Diameter

Protect, insulate, and bundle wires with this high-quality transparent heat shrink tubing. Made from ethylene vinyl acetate (EVA) copolymer with a 2:1 shrink ratio, it provides reliable electrical insulation and mechanical protection for wire splices, solder joints, terminal connections, and cable management applications across a wide temperature range of −55°C to +125°C.

The transparent finish allows visual inspection of the connection underneath — ideal for quality control in professional wiring and electronics assembly.

Specifications

• Material: Ethylene Vinyl Acetate (EVA) copolymer
• Shrink Ratio: 2:1
• Color: Transparent (clear)
• Inner Diameter (before shrink): 1mm / 1.5mm / 2mm / 2.5mm
• Temperature Resistance: −55°C to +125°C
• Shrink Temperature: ~70°C (begins shrinking); fully shrunk at ~100°C
• Dielectric Strength: ≥1,500V/mm
• Tensile Strength: ≥10 MPa
• Elongation at Break: ≥200%

Available Sizes & Lengths

• Inner Diameter: 1mm, 1.5mm, 2mm, 2.5mm
• Length Options: 2m (1 roll), 4m (2 rolls), 6m (3 rolls), 10m (5 rolls)

Wire Gauge Compatibility Guide

• 1mm ID: Suitable for AWG 28–24 (0.08–0.2mm²)
• 1.5mm ID: Suitable for AWG 24–22 (0.2–0.35mm²)
• 2mm ID: Suitable for AWG 22–20 (0.35–0.5mm²)
• 2.5mm ID: Suitable for AWG 20–18 (0.5–0.75mm²)

Key Features

• Transparent: Inspect solder joints and wire connections without removing the sleeve
• Wide temperature range: Suitable for automotive, industrial, and outdoor applications
• Flexible after shrinking: Does not become brittle at low temperatures
• Chemical resistance: Resistant to oils, fuels, and common solvents
• RoHS compliant: Halogen-free, lead-free construction

How to Use

1. Select tubing with inner diameter 1.5×–2× the diameter of the wire or connector
2. Slide tubing over wire before making the connection
3. Position tubing over the joint or splice
4. Apply heat evenly using a heat gun (recommended) or lighter from a distance
5. Tubing shrinks uniformly to conform tightly to the wire

Typical Applications

• Wire splice and solder joint insulation
• Terminal and connector strain relief
• Cable bundling and labeling
• PCB component lead insulation
• Automotive wiring harness repair
• Marine and outdoor electrical connections
• DIY electronics and hobby projects

Package Contents

• Transparent heat shrink tubing rolls (inner diameter and length as selected)
