936777-2 / 936780-2 Automotive 20-Pin Composite Connector — Engine Wiring Harness
The 936777-2 (male) and 936780-2 (female) are 20-pin automotive composite connectors for engine electric wiring harness modification and repair applications. These TE Connectivity-referenced part numbers are used in engine management, body control, and custom wiring harness applications requiring a 20-pin composite connector interface. The composite design accommodates mixed terminal pitches or circuit types within a single housing — combining signal, power, and ground circuits in one connector.
Key Specifications
| Parameter | Value |
|---|---|
| Part Numbers | 936777-2 (male) / 936780-2 (female) |
| Pin Count | 20-pin |
| Type | Composite (mixed circuit) connector |
| Housing Material | PA66 glass-filled nylon |
| Terminal Material | Tin-plated copper alloy |
| Operating Temperature | -40°C to +125°C |
| Locking | Positive snap-latch |
| Compliance | RoHS |
Typical Applications
- Engine wiring harness modification and repair
- Custom ECU wiring harness fabrication
- Body control module connector replacement
- 20-pin composite connector repair on multiple vehicle platforms
Frequently Asked Questions
Q: What is a composite automotive connector?
