JST SH 1.0mm SMT Horizontal Header — BMO2B / BMO3B / BMO4B-SRSS-TB

The JST SH 1.0mm SMT horizontal header (BMO2B/BMO3B/BMO4B-SRSS-TB) is the PCB-side connector for SH-series cables in FPV drones, wearables, and compact IoT devices. Surface-mount, horizontal (side-entry) orientation — the cable exits parallel to the PCB surface, the standard orientation for most drone and wearable PCB designs.

Key Features

• JST SH 1.0mm pitch — mates with all SH-series female housings and pre-crimped cables
• BMO series SMT headers — genuine JST BMO2B/BMO3B/BMO4B-SRSS-TB, horizontal orientation
• 2, 3, and 4 pin options — the most common SH-series pin counts for drone and wearable PCBs
• Reflow solder compatible — standard SMT reflow soldering process
• 1A / 50V rating — suitable for signal and low-current power lines
• Temperature Range: −25°C to +85°C
• RoHS compliant

Typical Applications

• FPV drone flight controller and ESC PCB connector population
• Wearable electronics and fitness device PCB design
• Miniature IoT sensor and module PCB connector population
• Custom PCB design requiring SH-series wire-to-board connections

Technical Specifications

• Connector Series: JST SH / BMO Series
• Part Numbers: BMO2B-SRSS-TB, BMO3B-SRSS-TB, BMO4B-SRSS-TB
• Pitch: 1.0 mm
• Pin Counts: 2, 3, 4
• Mount Type: SMT (Surface Mount)
• Orientation: Horizontal (side-entry)
• Voltage Rating: 50V
• Current Rating: 1A per contact
• Temperature Range: −25°C to +85°C
• RoHS Compliant: Yes
• Brand: Keszoox
• Origin: Mainland China
