JST XH 2.5mm Connector Kit — 2P–10P, 22AWG Pre-Crimped Terminal Wires

JST XH 2.5mm Connector Kit — 2P–10P, 22AWG Pre-Crimped Terminal Wires

The JST XH 2.5mm is one of the most widely used wire-to-board connectors in 3D printers, RC models, and Arduino projects. This complete kit includes XHP female locking housings, B-XH PCB headers, SXH-001T-P0.6 crimp terminals, and 22AWG pre-crimped terminal wire assemblies in assorted pin counts from 2P to 10P. Rated 3A / 250V AC/DC. The positive-latch locking housing ensures secure mating and resists accidental disconnection.

Why Choose This Kit?

• ✅ JST XH 2.5mm standard — the most widely used connector in 3D printer mainboards, RC models and Arduino shields
• ✅ Complete assortment — XHP housings, B-XH headers, SXH-001T terminals and 22AWG wires in one pack
• ✅ 22AWG pre-crimped terminal wires — ready to insert, no crimping tool required
• ✅ Positive-latch locking housing — secure mating, resists accidental disconnection
• ✅ 3A / 250V AC/DC rated — suitable for signal and low-power wiring
• ✅ 2P–10P assortment — covers the most common pin counts for prototyping and production
• ✅ RoHS compliant — PA nylon housing, tin-plated copper contacts

Kit Contents

• XHP-NN Female Locking Housings — 2P to 10P assorted
• B-XH DIP PCB Headers — top-entry through-hole, tin-plated contacts
• SXH-001T-P0.6 Crimp Terminals — AWG #22–#28, phosphor bronze, tin-plated
• 22AWG Pre-Crimped Terminal Wire Assemblies — assorted pin counts

Key Specifications

• Series: JST XH | Pitch: 2.5mm | Pin counts: 2P–10P
• Current rating: 3A | Voltage: 250V AC/DC | Temperature: −25°C to +85°C
• Wire: 22AWG | Contact: SXH-001T-P0.6, phosphor bronze, tin-plated
• Housing: PA nylon | Compliance: RoHS compliant

Typical Applications

• 3D printer mainboard sensor, fan, heated bed and stepper motor wiring
• RC model and drone internal power and signal wiring
• Arduino, ESP32 and development board wire-to-board connections
• IoT sensor and smart home device PCB connections
• Robotics and CNC machine signal and power wiring
