KBL410 Single-Phase Diode Bridge Rectifier — 4A, 1000V, KBL Package (3-Pack)

KBL410 Single-Phase Diode Bridge Rectifier — 4A, 1000V (3-Pack)

The KBL410 is a single-phase full-wave bridge rectifier rated at 4A average forward current and 1000V peak inverse voltage (PIV). In KBL package with a central mounting hole for heatsinking, it converts AC mains voltage to pulsating DC for linear power supplies, transformer-based rectifiers, and battery chargers. Supplied as a 3-pack.

Key Specifications

Parameter	Value
Part Number	KBL410 / KBL-410
Package	KBL (bolt-mount, 4-pin)
Average Forward Current	4A
Peak Inverse Voltage (PIV)	1000V
Forward Voltage Drop	~1.1V per diode (2.2V total)
Operating Temperature	-55°C to +150°C
Mounting	Central bolt hole (M4)
Pack Quantity	3 pieces

KBL Series Selection Guide

Part	Current	Voltage
KBL401	4A	100V
KBL404	4A	400V
KBL406	4A	600V
KBL410	4A	1000V

Why Choose KBL410?

• ✅ 1000V PIV — safe margin for 230V AC mains rectification (peak ~325V)
• ✅ 4A rating — suitable for up to ~40W linear power supply loads
• ✅ KBL bolt-mount package — easy heatsinking via chassis or heatsink plate
• ✅ 3-pack value — spares for repair and new builds

Typical Applications

• Transformer-based linear power supply rectifier
• AC-DC battery charger rectifier stage
• Mains-powered audio amplifier PSU
• Industrial AC-DC converter rectifier
• Welding machine and motor drive rectifier

Package Contents

• 3 × KBL410 Single-Phase Bridge Rectifier
