DT-06 WiFi Serial TTL Module — Transparent Transmission, HC-06 Compatible, ESP-M2

The DT-06 is a compact WiFi serial transparent transmission module built on the ESP-M2 (ESP8266) chip. It is designed as a drop-in replacement for the Bluetooth HC-06 module — sharing the same 4-pin footprint (VCC, GND, TX, RX) and transparent serial bridge behavior, but transmitting data over WiFi instead of Bluetooth. This makes it ideal for upgrading existing HC-06 Arduino projects to WiFi without code changes.

Key Specifications

Parameter	Value
Core Module	ESP-M2 (ESP8266)
WiFi Standard	802.11 b/g/n, 2.4GHz
Interface	UART (TX, RX, VCC, GND)
Supply Voltage	3.3V or 5V (onboard LDO)
Transmission Mode	Transparent serial (TCP/UDP)
HC-06 Pin Compatible	Yes (same 4-pin layout)
Configuration	AT commands or web configuration page
Operating Mode	STA (client) or AP (hotspot)

DT-06 vs HC-06 — WiFi Upgrade Path

Feature	DT-06 (WiFi)	HC-06 (Bluetooth)
Protocol	WiFi (TCP/UDP)	Bluetooth Classic
Range	Up to 100m (WiFi)	~10m
iOS Compatible	✅ Yes (via TCP)	❌ No
Pin Layout	Same as HC-06	Standard
Configuration	AT commands / web page	AT commands

Why Choose DT-06?

✅ HC-06 pin compatible — swap into existing HC-06 socket without PCB changes
✅ WiFi range — up to 100m vs 10m for Bluetooth
✅ iOS compatible — connect from iPhone via TCP socket app
✅ 3.3V / 5V supply — onboard LDO, works with 5V Arduino directly
✅ Web configuration — set SSID/password via browser, no AT commands needed
