3-Pin Auto Rearview Mirror Connector — 03T-JWPF-VSLE-S / 03R-JWPF-VSLE-S / B03B-JWPF-SK-R | JST JWPF Series
OEM-compatible JST JWPF-series 3-pin waterproof connector for automotive rearview mirror wiring harnesses. Cross-references 03T-JWPF-VSLE-S (male plug), 03R-JWPF-VSLE-S (female socket), and B03B-JWPF-SK-R (PCB header) — used for power folding mirror, heated mirror, and camera-integrated mirror wiring circuits across multiple vehicle platforms.
Specifications
| Parameter | Value |
|---|---|
| Pin Count | 3 |
| Connector Series | JST JWPF (waterproof) |
| OEM Part Numbers | 03T-JWPF-VSLE-S (male) / 03R-JWPF-VSLE-S (female) / B03B-JWPF-SK-R (PCB header) |
| Housing Material | PA66 (Nylon 66) |
| Sealing | Rubber wire seal (waterproof) |
| Waterproof Rating | IP67 |
| Gender | Male (03T) + Female (03R) + PCB header (B03B) |
| Operating Temperature | -40°C to +105°C |
| Application | Rearview mirror (power fold, heated, camera) |
| Certification | CE |
Compatible Vehicles & Applications
- Power folding mirror wiring harness connector on Japanese and European vehicles
- Heated mirror element connector repair on Toyota / Honda / Nissan platforms
- Camera-integrated mirror wiring connector for dashcam and OEM camera systems
- General automotive rearview mirror harness repair using JST JWPF 3-pin connectors
- Aftermarket power folding mirror kit installation requiring JST JWPF waterproof connectors
Why Choose This Connector?
- ✅ JST JWPF OEM-spec series — industry-standard waterproof connector for automotive mirror circuits
- ✅ 3 variants: male plug + female socket + PCB header — covers all harness connection points
- ✅ IP67 rubber wire seal — protects against rain and car wash water ingress at mirror base
- ✅ Positive locking latch — secure connection resistant to mirror vibration
- ✅ CE certified — meets EU automotive electrical standards
Comparison: JST JWPF vs Other Mirror Connector Series
| Series | Waterproof | Pin Count | Application |
|---|---|---|---|
| JST JWPF (this) | IP67 | 2–6 pin | Automotive mirror, exterior sensors |
| JST SM | Non-sealed | 2–15 pin | Interior electronics, PCB connections |
| JST PH | Non-sealed | 2–16 pin | General electronics, battery packs |
Application Scenarios
- Power folding mirror connector replacement after mirror assembly swap
- Heated mirror wiring harness repair on Toyota Camry / Corolla / RAV4
- Camera mirror connector restoration on vehicles with integrated dashcam or OEM camera
- Aftermarket power folding mirror kit wiring using JST JWPF waterproof connectors
FAQ
Q: What is the difference between 03T-JWPF-VSLE-S and 03R-JWPF-VSLE-S?
A: 03T-JWPF-VSLE-S is the male plug (wire-to-wire, pin side). 03R-JWPF-VSLE-S is the female socket (wire-to-wire, receptacle side). B03B-JWPF-SK-R is the PCB-mount header (board side). All three are part of the JST JWPF 3-pin series.
Q: Is the JST JWPF series compatible with other JST waterproof series?
A: No. The JWPF series has a unique housing geometry and is not cross-compatible with JST SM, PH, or other series. Always verify the exact series before ordering.
Q: What terminals are compatible?
A: JST JWPF female crimp terminals (part SWPT-001T-P025 or equivalent) for 0.13–0.33mm² (AWG 26–22) wire. Terminals are sold separately.
Package Contents
- 1× Male Connector (03T-JWPF-VSLE-S) and/or Female Connector (03R-JWPF-VSLE-S) as selected
- Terminals not included
