Molex PicoBlade MX1.25mm SMT Header Kit — Assorted Pin Counts
Molex PicoBlade MX1.25mm SMT Header Kit Assorted Pin Counts
Couldn't load pickup availability
Molex PicoBlade MX1.25mm SMT Header Kit — Assorted Pin Counts
Assorted kit of Molex PicoBlade 1.25mm SMT headers covering multiple pin counts — includes both 53047 SMT vertical (top-entry) and 53048 SMT right-angle (side-entry) headers. All headers mount on the PCB surface via reflow soldering and mate with Molex PicoBlade female housings (51021 series) loaded with 50079-8100 contacts. Rated 1A / 50V AC/DC, ideal for FPV drones, wearables, GPS modules, and compact IoT devices.
Why Choose This Kit?
- ✅ SMT vertical + right-angle headers — both orientations in one kit for maximum PCB layout flexibility
- ✅ Ultra-compact 1.25mm pitch — smallest Molex wire-to-board header, ideal for space-critical PCB designs
- ✅ Reflow solder compatible — no through-hole drilling required, compatible with standard SMT assembly processes
- ✅ Assorted 2–10 pin counts — covers the most common configurations for miniaturized electronics
- ✅ Mates with 51021 + 50079-8100 — standard PicoBlade cable assembly system
- ✅ RoHS2 compliant
Kit Contents
- 53047-NN SMT Vertical Headers — Top-entry, surface-mount, 1.25mm pitch, assorted pin counts
- 53048-NN SMT Right-Angle Headers — Side-entry, surface-mount, 1.25mm pitch, assorted pin counts
Key Specifications
- Pitch: 1.25mm | Pin counts: 2–10 pin (assorted)
- Current rating: 1A per contact | Voltage: 50V AC/DC
- Mounting: SMT — reflow solder compatible | Temperature: −25°C to +85°C
- Mating housing: Molex PicoBlade 51021 with 50079-8100 contacts
- Contact: tin-plated phosphor bronze | Housing: PA66 nylon
- Compliance: RoHS2 compliant
Typical Applications
- FPV drone flight controllers, ESCs and gimbal PCB headers
- GPS, telemetry and RC receiver module PCB connections
- Wearable electronics and fitness device sensor boards
- Compact IoT sensors, BLE modules and smart home device PCBs
- Raspberry Pi Zero, Arduino Nano and miniature SBC add-on boards
