FDS Series Dual MOSFET IC — SOP-8, FDS4559 / FDS9926A / FDS4935A / FDS6930B (5-Pack)

FDS Series Dual MOSFET IC — SOP-8 (5-Pack)

The FDS series from onsemi (formerly Fairchild) are dual MOSFET ICs in SOP-8 package, widely used in laptop power management, battery protection circuits, motor drivers, and SMPS designs. Each SOP-8 package contains two MOSFETs in complementary or same-type configurations, making them ideal for synchronous rectification, H-bridge, and load switch applications.

Variant Overview

Part	Configuration	Vds	Id	Typical Use
FDS4559	N + P channel	60V	9A / 7A	H-bridge, motor driver
FDS9926A	Dual N-channel	20V	6.5A each	Laptop battery switch, sync rectifier
FDS4935A	Dual P-channel	-30V	-4A each	Load switch, battery protection
FDS6930B	Dual N-channel	30V	5A each	Synchronous buck converter

Common Specifications

Parameter	Value
Package	SOP-8
Gate Threshold	1–2.5V (logic-level compatible)
RDS(on)	Low (variant dependent)
Pack Quantity	5 pieces

Why Choose FDS Series?

• ✅ SOP-8 package — compact dual MOSFET in standard SMD footprint
• ✅ Logic-level gate drive — driven directly from 3.3V / 5V MCU or gate driver
• ✅ Multiple configurations — N+P, dual-N, dual-P for different circuit topologies
• ✅ 5-pack value — stock for repair and production

Typical Applications

• Laptop battery charge/discharge MOSFET replacement
• Synchronous buck converter switch pair
• H-bridge motor driver
• Battery protection circuit MOSFET
• SMPS synchronous rectifier

Package Contents

• 5 × FDS Series Dual MOSFET IC SOP-8 (variant as selected)
