MKP Metal Film Audio Capacitor 100V 1.5µF 2.2µF 3.3µF High-Fidelity HIFI Coupling Frequency
MKP Metal Film Audio Capacitor 100V 1.5µF 2.2µF 3.3µF High-Fidelity HIFI Coupling Frequency
Couldn't load pickup availability
MKP Metal Film Audio Capacitor — 100V, 1.5µF / 2.2µF / 3.3µF, HIFI Coupling & Crossover
High-quality MKP (Metallised Polypropylene) film capacitors rated at 100V DC, available in 1.5µF, 2.2µF, and 3.3µF values for high-fidelity audio applications. MKP capacitors offer significantly lower ESR, lower dielectric absorption, and lower distortion than standard electrolytic capacitors, making them the preferred choice for audio signal coupling, loudspeaker crossover networks, and frequency divider circuits in HIFI and audiophile audio equipment.
Technical Specifications
| Parameter | Value |
|---|---|
| Capacitor Type | MKP (Metallised Polypropylene Film) |
| Capacitance Values | 1.5µF / 2.2µF / 3.3µF (select variant) |
| Rated Voltage | 100V DC |
| Tolerance | ±5% (J grade) |
| Dielectric | Polypropylene (PP) |
| ESR | Very low (film capacitor) |
| Dielectric Absorption | <0.01% (polypropylene) |
| Operating Temperature | −40°C to +85°C |
| Lead Pitch | Standard through-hole (radial) |
| Certification | RoHS |
MKP vs Electrolytic Capacitor for Audio
| Parameter | MKP Film | Electrolytic |
|---|---|---|
| ESR | Very low (<0.1Ω) | Higher (1–10Ω) |
| Dielectric Absorption | <0.01% | 1–5% |
| Distortion | Extremely low | Higher |
| Polarity | Non-polarised | Polarised (bipolar for audio) |
| Frequency Response | Flat to MHz | Rolls off above kHz |
| Audio Suitability | Preferred for signal path | Acceptable for power supply |
Typical Applications
- Loudspeaker Crossover: Series and shunt capacitors in 2-way and 3-way passive loudspeaker crossover networks for tweeter high-pass and midrange bandpass filters
- Audio Signal Coupling: DC-blocking coupling capacitor in the signal path of preamplifiers, tone controls, and audio amplifier input/output stages
- Frequency Divider: Capacitor in active and passive frequency divider circuits for subwoofer crossover and high-pass filter applications
- Amplifier Bypass: Bypass capacitor across electrolytic power supply capacitors in audio amplifiers to improve high-frequency performance
- HIFI Upgrade: Replace standard electrolytic coupling capacitors in vintage amplifiers and preamplifiers with MKP film capacitors for improved audio transparency
FAQ
Q: Can I use MKP capacitors in AC circuits?
A: MKP capacitors are non-polarised and can be used in AC signal circuits. For mains AC applications (X2 capacitors), use specifically rated X2 MKP capacitors. These 100V DC rated capacitors are for audio signal and low-voltage AC applications only.
Q: What value should I use for a tweeter crossover at 3kHz?
A: For a first-order (6dB/octave) high-pass crossover at 3kHz with an 8Ω tweeter: C = 1 / (2π × f × R) = 1 / (2π × 3000 × 8) ≈ 6.6µF. Use two 3.3µF MKP capacitors in parallel for this value.
Package Contents
- MKP metal film audio capacitor (value as selected: 1.5µF / 2.2µF / 3.3µF, 100V)
