DJ622-F0.4A H62 Brass Tinned 0.4mm Automotive Splice Terminal — G371 / 917308-1 | 50PCS
DJ622-F0.4A H62 Brass Tinned 0.4mm Automotive Splice Terminal G371 / 917308-1 | 50PCS
Couldn't load pickup availability
DJ622-F0.4A H62 Brass Tinned 0.4mm Automotive Splice Terminal — G371 / 917308-1
Premium-grade H62 brass tinned 0.4mm series automotive splice crimp terminal (DJ622-F0.4A, cross-reference G371 / 917308-1) for ultra-high-density automotive ECU and control module wiring harness applications. Manufactured from H62 brass (65% copper, 35% zinc) with a tin plating finish, these terminals deliver superior conductivity, corrosion resistance, and crimp retention compared to standard copper alloy alternatives. Designed for the most demanding fine-pitch automotive connector applications where signal integrity and long-term reliability are critical. Supplied in a 50PCS pack.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Numbers | DJ622-F0.4A / G371 / 917308-1 |
| Terminal Pitch | 0.4mm series (ultra-fine pitch) |
| Gender | Female (splice crimp contact) |
| Material | H62 brass (65% Cu / 35% Zn), tin-plated |
| Wire Range | 0.08–0.13mm² (AWG 28–26) |
| Pack Quantity | 50PCS |
| Certification | CE |
| Origin | Mainland China |
Key Features
- ✅ H62 brass construction — superior conductivity and mechanical strength vs. standard copper alloy terminals
- ✅ Tin-plated finish — enhanced corrosion resistance and solderability for long-term automotive reliability
- ✅ 0.4mm ultra-fine pitch — for the highest-density automotive ECU and control module connectors
- ✅ G371 / 917308-1 cross-reference — compatible with Tyco / TE Connectivity 917308-1 series connector applications
- ✅ CE certified — meets European automotive electrical component standards
Common Applications
- High-density automotive ECU connector terminal replacement (0.4mm pitch)
- Body control module (BCM) fine-wire harness repair
- Automotive sensor circuit ultra-fine pitch connector re-termination
- Modern vehicle ADAS, infotainment, and powertrain wiring harness repair
- Custom high-density automotive wiring harness fabrication
Crimping Guide
- Strip 2–3mm of insulation from the wire end using a precision wire stripper.
- Insert the wire into the terminal crimp barrel under magnification.
- Crimp using a precision ratchet crimping tool with the appropriate 0.4mm series die.
- Inspect the crimp under magnification to verify correct wire barrel and insulation barrel engagement.
- Insert the crimped terminal into the connector housing until it clicks into the retention position.
FAQ
Q: What is the difference between H62 brass and standard copper alloy terminals?
A: H62 brass (65% Cu / 35% Zn) offers higher mechanical strength and better spring retention than standard copper alloy, making it more suitable for fine-pitch terminals that require consistent contact force over many mating cycles.
Q: What wire gauge is compatible?
A: Designed for 0.08–0.13mm² (AWG 28–26) ultra-fine wire, typical for modern automotive ECU signal circuits.
Package Contents
- 50× DJ622-F0.4A H62 Brass Tinned 0.4mm Automotive Splice Terminal (G371 / 917308-1)
