JST XH 2.54mm 10-Pin Cable — Custom Length & Color, 22AWG Pre-Crimped

JST XH 2.54mm 10-Pin Single-Head Pre-Crimped Cable — 22AWG, 3A/250V

Ten conductors represent the maximum pin count in the standard JST XH 2.54mm series and serve the most demanding single-connector interface requirements in electronics assembly: full parallel data buses, high-density sensor arrays, multi-axis motion systems with complete control lines, and custom PCB interfaces that consolidate an entire subsystem's wiring into a single locking connector. This single-head pre-crimped cable delivers ten factory-crimped JST XH terminals on one end, ready to seat into any standard XH 10-pin housing, with the other end bare for soldering, Dupont termination, or custom connector assembly.

At ten conductors, factory crimping is the only practical choice for reliable assembly. Machine crimping applies consistent, calibrated force to every one of the ten contacts — eliminating the insulation damage, cold joints, and inconsistent contact force that make hand-crimped 10-wire assemblies unreliable. The result is a harness that performs identically under vibration, thermal cycling, and thousands of mating cycles.

22AWG stranded copper wire rated at 3A/250V handles mixed power-and-signal applications across the full 10-pin XH range. Available in 8 lengths from 10cm to 80cm and 8 wire colors for precise routing and color-coding.

Technical Specifications

• Connector System: JST XH series, 2.54mm pitch
• Pin Count: 10-pin
• Configuration: Single-head — one end crimped (XH terminals), one end bare wire
• Wire Gauge: 22AWG stranded copper
• Current Rating: 3A per contact
• Voltage Rating: 250V AC/DC
• Contact Material: Copper alloy, tin-plated
• Insulation: PVC, UL-rated
• Locking Mechanism: Positive latch lock
• Available Lengths: 10cm / 20cm / 30cm / 40cm / 50cm / 60cm / 70cm / 80cm
• Available Colors: Red, Black, White, Yellow, Blue, Green, Orange, Purple
• Pitch: 2.54mm (0.1 inch)
• RoHS Compliant: Yes

Typical Applications

• Full Parallel Data Buses: 8-bit data bus with address/control lines, parallel LCD interfaces in full 8-bit mode with all control signals
• Multi-Axis CNC & Motion Control: 4-axis stepper systems with step/dir/enable per axis plus shared power and ground, advanced motion controller harnesses
• High-Density Sensor Arrays: Multi-channel analog input assemblies, 10-wire instrument connections, complex sensor fusion modules
• 3D Printers: Complete toolhead harnesses combining heater, thermistor, dual fans, probe, filament sensor, and LED in a single connector
• Custom PCB Interfaces: Multi-subsystem consolidation harnesses, backplane connections, complex shield interfaces
• Industrial & Automation: 10-channel relay modules, high-density PLC I/O connections, multi-axis encoder assemblies
• Arduino & Microcontrollers: Complex multi-peripheral interfaces, custom bus wiring, high pin-count shield connections

Compatibility

Compatible with JST XH series 10-pin housings (JST part: XHP-10) and all 2.54mm pitch PCB headers with XH-compatible locking geometry. Bare wire end accepts Dupont 2.54mm housings, screw terminals, or direct PCB soldering.

Housing not included. This listing is for the pre-crimped wire only.
