1376103-1 / 1473413-1 / 1318917-1 Automotive 24-Pin Rearview Mirror Connector
The 1376103-1, 1473413-1, and 1318917-1 are 24-pin automotive connector housings for rearview mirror and camera system wiring harness applications. These TE Connectivity-referenced part numbers are used in electrically adjustable mirror, heated mirror, auto-dimming mirror, and integrated camera system wiring harnesses across multiple vehicle platforms. The 24-pin configuration accommodates the multiple circuits required for modern mirror assemblies: motor control, heating element, camera signal, turn signal indicator, and power/ground.
Key Specifications
| Parameter | Value |
|---|---|
| Part Numbers | 1376103-1 / 1473413-1 / 1318917-1 |
| Pin Count | 24-pin |
| Application | Rearview mirror / camera system |
| Sealing | Unsealed |
| Housing Material | PA66 glass-filled nylon |
| Terminal Material | Tin-plated copper alloy |
| Operating Temperature | -40°C to +85°C |
| Compliance | RoHS |
Modern Mirror Assembly Wiring Requirements
- Multiple circuits in one connector — modern electrically adjustable mirrors with heating, auto-dimming, turn signal, and integrated camera require 15–25 circuits; a 24-pin connector consolidates all circuits in a single connection point
- Low-current signal circuits — camera video signal, auto-dimming sensor, and mirror position feedback are low-current circuits requiring clean, low-resistance terminal contacts
- OEM dimensions — manufactured to TE Connectivity mating specifications for direct replacement compatibility
Typical Applications
- Electrically adjustable rearview mirror connector repair
- Heated mirror wiring harness replacement
- Auto-dimming mirror connector repair
- Integrated rearview camera connector replacement
- Turn signal mirror indicator wiring repair
Frequently Asked Questions
Q: Why does a mirror need a 24-pin connector?
Modern premium mirrors integrate multiple functions: electric adjustment (2 motors × 2 directions = 4 circuits), heating element (2 circuits), auto-dimming (sensor + control = 3 circuits), integrated turn signal (2 circuits), camera video signal (2 circuits), power and ground (2 circuits), plus spare circuits for future features. A 24-pin connector accommodates all these functions in a single, reliable connection point.
