5.08mm Right-Angle Pin Header, Phoenix Contact, 2–24P

Phoenix Contact 5.08mm Right-Angle Pin Header — 2–24P, MC Series, 12A/300V

The Phoenix Contact MC series 5.08mm right-angle pin header (MC 1,5/…-GF-5,08) mounts horizontally on the PCB, with the mating direction parallel to the board surface. Ideal for space-constrained enclosures where vertical clearance is limited. Mates with the MC 1,5/…-ST-5,08 plug connector.

• Pitch: 5.08mm
• Positions: 2 to 24 pins
• Mount type: Right-angle (horizontal) THT PCB mount
• Wire range (plug side): 0.14–2.5 mm² (28–12 AWG)
• Rating: 12A / 300V AC/DC
• Housing: Green, UL94 V-0 flame-retardant polyamide
• Contact: Tin-plated copper alloy
• Mating plug: Phoenix Contact MC 1,5/…-ST-5,08
• Compliance: RoHS2, UL Listed

Typical applications: Narrow enclosures, PLC systems, industrial automation panels, power distribution boards where vertical connector clearance is restricted.
